Brain Tumor Detection Using Python + ML

When I started working on Brain Tumor Detection, I honestly just wanted a project that felt real. Not another CRUD app, not another fake dataset demo. I wanted something that could actually matter, even if it’s only a student version.

So I built this Student Portfolio Project: an end-to-end web app where you upload an MRI scan and a deep learning model tells you whether it looks like a tumor or not. It runs with Flask + PyTorch, and yes, I struggled a lot before it finally worked.

The “Why”: Why You Should Build This Project

What made Brain Tumor Detection special for me:

• It feels like a real-world medical use case
• It connects deep learning + web development
• It’s impressive for interviews and portfolios
• And, honestly, it forced me to understand CNNs properly (not just copy code)

Tech Stack (and Why I Chose It)

Here’s what powers this project (from the repo ):

• Python – main language
• PyTorch – for building and running the CNN
• Flask – lightweight backend web framework
• HTML/CSS – frontend interface
• OpenCV / PIL – image preprocessing
• Pretrained .pth model – saved neural network weights

Why not TensorFlow?
I wanted to really understand tensors and backprop, and PyTorch felt more flexible. Also, many research labs use it, so learning PyTorch helps long-term.

Why Flask?
Because it’s simple. I didn’t want Django complexity for a small ML web app.

The Logic: How the Project Actually Works

At a high level, the flow is:

1. User uploads MRI image
2. Flask receives the image
3. Image is preprocessed
4. CNN model runs prediction
5. Result is shown on the page

But the real learning happened inside the src folder ():

1. Dataset Loader (dataset.py)

This script reads MRI images from two folders:

• tumor
• non-tumor

It resizes every image to 64×64, converts it to grayscale, and normalizes pixel values between 0 and 1. That part confused me at first, but now I see why consistency matters.

2. CNN Model (model.py)

It’s a Convolutional Neural Network with:

• Conv layers to extract features
• Max pooling to reduce size
• Fully connected layers to classify

3. Training Script (train.py)

• Loads the dataset
• Feeds it to the CNN
• Calculates loss
• Updates weights

Flask Web App: From Terminal to Browser

Inside the app/ folder (), the magic happens.

The file app.py:

• Loads the pretrained model
• Accepts image uploads
• Runs the prediction
• Sends the result back to HTML

The UI is simple but functional:

• Upload MRI image
• Click submit
• See “Tumor” or “Non-Tumor”

This is where I felt like a real developer, not just a student running notebooks.

How to Run It (Beginner Step-by-Step Guide)

Step 1: Download the Project

cd Brain-Tumor-Detection

Step 2: Create Virtual Environment

python -m venv venv
venv\Scripts\activate   # Windows
source venv/bin/activate  # Mac/Linux

Step 3: Install Requirements

pip install -r requirements.txt

Step 4: Download the Model

Download the .pth model and place it in:

model/brain_tumor_model.pth

Step 5: Run the App

cd app
python app.py

Now open:

http://127.0.0.1:5000/

Upload an MRI image and test it.

What I’d Do Differently

• Use Transfer Learning instead of a basic CNN
• Add probability scores instead of only labels
• Improve frontend UI
• Add model confidence warning

Screenshots

Why This Is a Great Student Portfolio Project

This project shows that you can:

• Work with medical image data
• Build deep learning models
• Integrate ML into a real web app
• Deploy predictions end-to-end

Download

Download Project File
